Philadelphia Last Mile Logistics Center at 95

Building Size: 81,156 sf

Building Dimensions: 450' x 180'

Office: 2,237 SF

Ceiling Height: 36'

Column Spacing: 60' D x 56' W

Dock Doors: 20 (9' x 10')

Drive-in Doors: 1 (14' x 14')

Car Parking: 87 car parking spaces

Fire Protection: ESFR system

Electric System: 1,200 amp, 480/277 volt, 3-phase service

Lighting System: 25fc at 30” AFF with motion sensors

Heating System: Roof mounted,, gas fired Cambridge units (60

degrees inside when 0 degrees outside)

Dock Equipment:

10 dock pit levelers (7’x8’ mechanical) with

35,000-pound capacity, bumpers, guards, and

seals

Water: 4” domestic supply

Sewer: 8” gravity sanitary line

Telephone/Data: Two (2) 4” conduits installed to the building’s

demarcation location

Construction Type: Precast load-bearing exterior walls

Floor:

7” thick, 4,000 PSI concrete slab

Floor load designed to average 800

lbs/SF

Roof: Single-ply 60 mil EPDM or TPO

membrane, fully adhered
